1. 什么是Hook

經常會聽到鉤子函數(hook function)這個概念，最近在看目標檢測開源框架mmdetection，里面也出現大量Hook的編程方式，那到底什么是hook？hook的作用是什么？

• what is hook ？鉤子hook，顧名思義，可以理解是一個掛鉤，作用是有需要的時候掛一個東西上去。具體的解釋是：鉤子函數是把我們自己實現的hook函數在某一時刻掛接到目標掛載點上。

• hook函數的作用 舉個例子，hook的概念在windows桌面軟件開發很常見，特別是各種事件觸發的機制; 比如C++的MFC程序中，要監聽鼠標左鍵按下的時間，MFC提供了一個onLeftKeyDown的鉤子函數。很顯然，MFC框架并沒有為我們實現onLeftKeyDown具體的操作，只是為我們提供一個鉤子，當我們需要處理的時候，只要去重寫這個函數，把我們需要操作掛載在這個鉤子里，如果我們不掛載，MFC事件觸發機制中執行的就是空的操作。

從上面可知

• hook函數是程序中預定義好的函數，這個函數處于原有程序流程當中（暴露一個鉤子出來）

• 我們需要再在有流程中鉤子定義的函數塊中實現某個具體的細節，需要把我們的實現，掛接或者注冊（register）到鉤子里，使得hook函數對目標可用

• hook 是一種編程機制，和具體的語言沒有直接的關系

• 如果從設計模式上看，hook模式是模板方法的擴展

• 鉤子只有注冊的時候，才會使用，所以原有程序的流程中，沒有注冊或掛載時，執行的是空（即沒有執行任何操作）

本文用python來解釋hook的實現方式，并展示在開源項目中hook的應用案例。hook函數和我們常聽到另外一個名稱：回調函數（callback function）功能是類似的，可以按照同種模式來理解。

2. hook實現例子

據我所知，hook函數最常使用在某種流程處理當中。這個流程往往有很多步驟。hook函數常常掛載在這些步驟中，為增加額外的一些操作，提供靈活性。

下面舉一個簡單的例子，這個例子的目的是實現一個通用往隊列中插入內容的功能。流程步驟有2個

• 需要再插入隊列前，對數據進行篩選 input_filter_fn

• 插入隊列 insert_queue

class ContentStash(object):     """     content stash for online operation     pipeline is     1. input_filter: filter some contents, no use to user     2. insert_queue(redis or other broker): insert useful content to queue     """      def __init__(self):         self.input_filter_fn = None         self.broker = []      def register_input_filter_hook(self, input_filter_fn):         """         register input filter function, parameter is content dict         Args:             input_filter_fn: input filter function          Returns:          """         self.input_filter_fn = input_filter_fn      def insert_queue(self, content):         """         insert content to queue         Args:             content: dict          Returns:          """         self.broker.append(content)      def input_pipeline(self, content, use=False):         """         pipeline of input for content stash         Args:             use: is use, defaul False             content: dict          Returns:          """         if not use:             return          # input filter         if self.input_filter_fn:             _filter = self.input_filter_fn(content)                      # insert to queue         if not _filter:             self.insert_queue(content)    # test ## 實現一個你所需要的鉤子實現：比如如果content 包含time就過濾掉，否則插入隊列 def input_filter_hook(content):     """     test input filter hook     Args:         content: dict      Returns: None or content      """     if content.get('time') is None:         return     else:         return content   # 原有程序 content = {'filename': 'test.jpg', 'b64_file': "#test", 'data': {"result": "cat", "probility": 0.9}} content_stash = ContentStash('audit', work_dir='')  # 掛上鉤子函數， 可以有各種不同鉤子函數的實現，但是要主要函數輸入輸出必須保持原有程序中一致，比如這里是content content_stash.register_input_filter_hook(input_filter_hook)  # 執行流程 content_stash.input_pipeline(content)

3. hook在開源框架中的應用

3.1 keras

在深度學習訓練流程中，hook函數體現的淋漓盡致。

一個訓練過程（不包括數據準備），會輪詢多次訓練集，每次稱為一個epoch，每個epoch又分為多個batch來訓練。流程先后拆解成：

• 開始訓練

• 訓練一個epoch前

• 訓練一個batch前

• 訓練一個batch后

• 訓練一個epoch后

• 評估驗證集

• 結束訓練

這些步驟是穿插在訓練一個batch數據的過程中，這些可以理解成是鉤子函數，我們可能需要在這些鉤子函數中實現一些定制化的東西，比如在訓練一個epoch后我們要保存下訓練的模型，在結束訓練時用最好的模型執行下測試集的效果等等。

keras中是通過各種回調函數來實現鉤子hook功能的。這里放一個callback的父類，定制時只要繼承這個父類，實現你過關注的鉤子就可以了。

@keras_export('keras.callbacks.Callback') class Callback(object):   """Abstract base class used to build new callbacks.    Attributes:       params: Dict. Training parameters           (eg. verbosity, batch size, number of epochs...).       model: Instance of `keras.models.Model`.           Reference of the model being trained.    The `logs` dictionary that callback methods   take as argument will contain keys for quantities relevant to   the current batch or epoch (see method-specific docstrings).   """    def __init__(self):     self.validation_data = None  # pylint: disable=g-missing-from-attributes     self.model = None     # Whether this Callback should only run on the chief worker in a     # Multi-Worker setting.     # TODO(omalleyt): Make this attr public once solution is stable.     self._chief_worker_only = None     self._supports_tf_logs = False    def set_params(self, params):     self.params = params    def set_model(self, model):     self.model = model    @doc_controls.for_subclass_implementers   @generic_utils.default   def on_batch_begin(self, batch, logs=None):     """A backwards compatibility alias for `on_train_batch_begin`."""    @doc_controls.for_subclass_implementers   @generic_utils.default   def on_batch_end(self, batch, logs=None):     """A backwards compatibility alias for `on_train_batch_end`."""    @doc_controls.for_subclass_implementers   def on_epoch_begin(self, epoch, logs=None):     """Called at the start of an epoch.      Subclasses should override for any actions to run. This function should only     be called during TRAIN mode.      Arguments:         epoch: Integer, index of epoch.         logs: Dict. Currently no data is passed to this argument for this method           but that may change in the future.     """    @doc_controls.for_subclass_implementers   def on_epoch_end(self, epoch, logs=None):     """Called at the end of an epoch.      Subclasses should override for any actions to run. This function should only     be called during TRAIN mode.      Arguments:         epoch: Integer, index of epoch.         logs: Dict, metric results for this training epoch, and for the           validation epoch if validation is performed. Validation result keys           are prefixed with `val_`.     """    @doc_controls.for_subclass_implementers   @generic_utils.default   def on_train_batch_begin(self, batch, logs=None):     """Called at the beginning of a training batch in `fit` methods.      Subclasses should override for any actions to run.      Arguments:         batch: Integer, index of batch within the current epoch.         logs: Dict, contains the return value of `model.train_step`. Typically,           the values of the `Model`'s metrics are returned.  Example:           `{'loss': 0.2, 'accuracy': 0.7}`.     """     # For backwards compatibility.     self.on_batch_begin(batch, logs=logs)    @doc_controls.for_subclass_implementers   @generic_utils.default   def on_train_batch_end(self, batch, logs=None):     """Called at the end of a training batch in `fit` methods.      Subclasses should override for any actions to run.      Arguments:         batch: Integer, index of batch within the current epoch.         logs: Dict. Aggregated metric results up until this batch.     """     # For backwards compatibility.     self.on_batch_end(batch, logs=logs)    @doc_controls.for_subclass_implementers   @generic_utils.default   def on_test_batch_begin(self, batch, logs=None):     """Called at the beginning of a batch in `evaluate` methods.      Also called at the beginning of a validation batch in the `fit`     methods, if validation data is provided.      Subclasses should override for any actions to run.      Arguments:         batch: Integer, index of batch within the current epoch.         logs: Dict, contains the return value of `model.test_step`. Typically,           the values of the `Model`'s metrics are returned.  Example:           `{'loss': 0.2, 'accuracy': 0.7}`.     """    @doc_controls.for_subclass_implementers   @generic_utils.default   def on_test_batch_end(self, batch, logs=None):     """Called at the end of a batch in `evaluate` methods.      Also called at the end of a validation batch in the `fit`     methods, if validation data is provided.      Subclasses should override for any actions to run.      Arguments:         batch: Integer, index of batch within the current epoch.         logs: Dict. Aggregated metric results up until this batch.     """    @doc_controls.for_subclass_implementers   @generic_utils.default   def on_predict_batch_begin(self, batch, logs=None):     """Called at the beginning of a batch in `predict` methods.      Subclasses should override for any actions to run.      Arguments:         batch: Integer, index of batch within the current epoch.         logs: Dict, contains the return value of `model.predict_step`,           it typically returns a dict with a key 'outputs' containing           the model's outputs.     """    @doc_controls.for_subclass_implementers   @generic_utils.default   def on_predict_batch_end(self, batch, logs=None):     """Called at the end of a batch in `predict` methods.      Subclasses should override for any actions to run.      Arguments:         batch: Integer, index of batch within the current epoch.         logs: Dict. Aggregated metric results up until this batch.     """    @doc_controls.for_subclass_implementers   def on_train_begin(self, logs=None):     """Called at the beginning of training.      Subclasses should override for any actions to run.      Arguments:         logs: Dict. Currently no data is passed to this argument for this method           but that may change in the future.     """    @doc_controls.for_subclass_implementers   def on_train_end(self, logs=None):     """Called at the end of training.      Subclasses should override for any actions to run.      Arguments:         logs: Dict. Currently the output of the last call to `on_epoch_end()`           is passed to this argument for this method but that may change in           the future.     """    @doc_controls.for_subclass_implementers   def on_test_begin(self, logs=None):     """Called at the beginning of evaluation or validation.      Subclasses should override for any actions to run.      Arguments:         logs: Dict. Currently no data is passed to this argument for this method           but that may change in the future.     """    @doc_controls.for_subclass_implementers   def on_test_end(self, logs=None):     """Called at the end of evaluation or validation.      Subclasses should override for any actions to run.      Arguments:         logs: Dict. Currently the output of the last call to           `on_test_batch_end()` is passed to this argument for this method           but that may change in the future.     """    @doc_controls.for_subclass_implementers   def on_predict_begin(self, logs=None):     """Called at the beginning of prediction.      Subclasses should override for any actions to run.      Arguments:         logs: Dict. Currently no data is passed to this argument for this method           but that may change in the future.     """    @doc_controls.for_subclass_implementers   def on_predict_end(self, logs=None):     """Called at the end of prediction.      Subclasses should override for any actions to run.      Arguments:         logs: Dict. Currently no data is passed to this argument for this method           but that may change in the future.     """    def _implements_train_batch_hooks(self):     """Determines if this Callback should be called for each train batch."""     return (not generic_utils.is_default(self.on_batch_begin) or             not generic_utils.is_default(self.on_batch_end) or             not generic_utils.is_default(self.on_train_batch_begin) or             not generic_utils.is_default(self.on_train_batch_end))

這些鉤子的原始程序是在模型訓練流程中的

keras源碼位置： tensorflowpythonkerasenginetraining.py

部分摘錄如下(## I am hook)：

# Container that configures and calls `tf.keras.Callback`s.       if not isinstance(callbacks, callbacks_module.CallbackList):         callbacks = callbacks_module.CallbackList(             callbacks,             add_history=True,             add_progbar=verbose != 0,             model=self,             verbose=verbose,             epochs=epochs,             steps=data_handler.inferred_steps)        ## I am hook       callbacks.on_train_begin()       training_logs = None       # Handle fault-tolerance for multi-worker.       # TODO(omalleyt): Fix the ordering issues that mean this has to       # happen after `callbacks.on_train_begin`.       data_handler._initial_epoch = (  # pylint: disable=protected-access           self._maybe_load_initial_epoch_from_ckpt(initial_epoch))       for epoch, iterator in data_handler.enumerate_epochs():         self.reset_metrics()         callbacks.on_epoch_begin(epoch)         with data_handler.catch_stop_iteration():           for step in data_handler.steps():             with trace.Trace(                 'TraceContext',                 graph_type='train',                 epoch_num=epoch,                 step_num=step,                 batch_size=batch_size):               ## I am hook               callbacks.on_train_batch_begin(step)               tmp_logs = train_function(iterator)               if data_handler.should_sync:                 context.async_wait()               logs = tmp_logs  # No error, now safe to assign to logs.               end_step = step + data_handler.step_increment               callbacks.on_train_batch_end(end_step, logs)         epoch_logs = copy.copy(logs)          # Run validation.          ## I am hook         callbacks.on_epoch_end(epoch, epoch_logs)

3.2 mmdetection

mmdetection是一個目標檢測的開源框架，集成了許多不同的目標檢測深度學習算法（pytorch版），如faster-rcnn, fpn, retianet等。里面也大量使用了hook，暴露給應用實現流程中具體部分。

詳見https://github.com/open-mmlab/mmdetection

這里看一個訓練的調用例子(摘錄)（https://github.com/open-mmlab/mmdetection/blob/5d592154cca589c5113e8aadc8798bbc73630d98/mmdet/apis/train.py）

def train_detector(model,                    dataset,                    cfg,                    distributed=False,                    validate=False,                    timestamp=None,                    meta=None):     logger = get_root_logger(cfg.log_level)      # prepare data loaders      # put model on gpus      # build runner     optimizer = build_optimizer(model, cfg.optimizer)     runner = EpochBasedRunner(         model,         optimizer=optimizer,         work_dir=cfg.work_dir,         logger=logger,         meta=meta)     # an ugly workaround to make .log and .log.json filenames the same     runner.timestamp = timestamp      # fp16 setting     # register hooks     runner.register_training_hooks(cfg.lr_config, optimizer_config,                                    cfg.checkpoint_config, cfg.log_config,                                    cfg.get('momentum_config', None))     if distributed:         runner.register_hook(DistSamplerSeedHook())      # register eval hooks     if validate:         # Support batch_size > 1 in validation         eval_cfg = cfg.get('evaluation', {})         eval_hook = DistEvalHook if distributed else EvalHook         runner.register_hook(eval_hook(val_dataloader, **eval_cfg))      # user-defined hooks     if cfg.get('custom_hooks', None):         custom_hooks = cfg.custom_hooks         assert isinstance(custom_hooks, list),              f'custom_hooks expect list type, but got {type(custom_hooks)}'         for hook_cfg in cfg.custom_hooks:             assert isinstance(hook_cfg, dict),                  'Each item in custom_hooks expects dict type, but got '                  f'{type(hook_cfg)}'             hook_cfg = hook_cfg.copy()             priority = hook_cfg.pop('priority', 'NORMAL')             hook = build_from_cfg(hook_cfg, HOOKS)             runner.register_hook(hook, priority=priority)

4. 總結

本文介紹了hook的概念和應用，并給出了python的實現細則。希望對比有幫助?？偨Y(jié)如下：

• hook函數是流程中預定義好的一個步驟，沒有實現

• 掛載或者注冊時， 流程執行就會執行這個鉤子函數

• 回調函數和hook函數功能上是一致的

• hook設計方式帶來靈活性，如果流程中有一個步驟，你想讓調用方來實現，你可以用hook函數
